JA Solar JAP60S01-280/SC Solar Panel
JA Solar JAP60S01-280/SC is a 280W polycrystalline silicon solar module designed for residential and commercial applications. It belongs to a legacy, time-tested module series known for its reliability, strict quality control, and anti-PID (Potential Induced Degradation) characteristics.
Key Technical Specifications
-
- Nominal Maximum Power (Pmax): 280 W
- Cell Type: Polycrystalline Silicon
- Number of Cells: 60 cells (6x10 configuration)
- Busbar Design: 5-busbar (5BB) technology for better current collection
- Module Efficiency: Up to 17.12%
- Dimensions: 1650 mm × 991 mm × 35 mm
- Weight: 18.2 kg
- Maximum System Voltage: 1000V DC
Performance & Mechanical Data
- Temperature Coefficient of Pmax: -0.40% / °C
- Frame: Anodized aluminum alloy with integrated drainage holes
- Junction Box: IP67 / IP68 rated protection
- Output Cables: 4.0 mm² solar cables with MC4 (or compatible) connectors
